RUVO 505 Pre-Hung Door Machine

The RUVO 505 Touch is the versatile workhorse at the center of any vertical- workflow door shop. It handles residential, commercial, architectural, and even labeled fire doors. It now features an even easier-to-use touchscreen-based control with a single Sequence button (and an Emergency Stop).

The RUVO 505 Touch adapts the innovative and proven concepts of the extensive RUVO pre-hung door machine line to this one versatile workhorse. The unit features a heavy duty power driven beveller/sizer, with routers to ease the door edges. Accurate target scales permit four hinge and jamb route location changes quickly and precisely.

  • The backset on hinges and locks are similarly handled. A hinge screw gun and predrill system are included.
  • There is a provision for accommodating both single and double beveled doors.
  • The RUVO 505 Touch works with residential, commercial, architectural and labeled fire doors.

Pre-Hung Door Equipment

Ruvo 505 Pre-Hung Door Machine


  • Electrical Standard: 4 wire:230 VAC, 3 PH, 25 AMPs
  • Air Requirements: .40 CFM @ 90 PSI, 1/2″ feeder airline
  • Machine Size: 18’L x 3’W x 7’H
  • Machine Weight: 3200 lbs.

Video Demonstration of RUVO 505


  • Max Door Height: 6′ to 9′ or ADA Specs:6′ to 8′”
  • Door Width: 1’6″ to 4′
  • Door Thickness: 1-3/8″ to 2-1/4″
  • Jamb Size/Styles: Up to 1 1/4″ x 10″, all styles
  • Hinge Size: 3-1/2″ to 5″ -OR- 3″ to 4-1/2″
  • Number of Hinges: Up to 4
  • Hinge Radius: 1/4″ or 5/8″
  • Hinge Backset: Scaled as required
  • Lock Bore Sizes: 2-1/8″ standard
  • Lock Bore Backset: Scaled to 5″
  • Lock Bore Latch plate: Up to 1 1/4″ x 10″, all styles

*Specifications are subject to change without notice.
